Viecar 4.0 OBD2 Bluetooth Scanner For IOS/Android Multi-brands 2015 New Arrival Viecar 4.0 Car Hud Display Function Resell Box
Super MINI ELM 327 Bluetooth
Attention: elm327 reader can do most of the OBDII vehicles, but it can\\\\\\\'t do all models. If any questions,please feel free to contact with the seller,please never open a dispute before contact with the seller.
The newly developed wireless scan tool.
It supports all OBD-II protocols.
It is the latest version V2.1
Bluetooth connection, no Batteries, Cables, or Switches.
Wireless (Bluetooth) 3~ 10 meters
Retrieve Fault Codes (DTCs) and clear Check Engine lights.
Can also be used with a PC with a Bluetooth Card.
Read diagnostic trouble codes, both generic and manufacturer-specific, and display their meaning (over 3000 generic code definitions in the database).
Clear trouble codes and turn off the MIL ("Check Engine" light)
Set the maximum number of responses to obtain
Remove spaces from ECU responses (to speed data transmission)
Store a unique identifier in EEPROM
Set the CAN mask and filter with one command
Easily switch between variable and fixed CAN message lengths
Send CAN remote frames (RTRs)
Display current sensor data, including:
Calculated Load Value
Fuel System Status
Short Term Fuel Trim
Long Term Fuel Trim
Intake Manifold Pressure
Intake Air Temperature
Air Flow Rate
Absolute Throttle Position
Oxygen sensor voltages/associated short term fuel trims
Fuel System status
1. ISO9141-2(5 baud init, 10.4Kbaud)
2. ISO14230-4 KWP (5 baud init, 10.4 Kbaud)
3. ISO14230-4 KWP (fast init, 10.4 Kbaud)
4. ISO15765-4 CAN (11bit ID, 500 Kbaud)
5. ISO15765-4 CAN (29bit ID, 500 Kbaud)
6. ISO15765-4 CAN (11bit ID, 250 Kbaud)
7. ISO15765-4 CAN (29bit ID, 250 Kbaud)
A.SAE J1939 CAN (29bit ID, 250*Kbaud)
B.USER1 CAN (11*bit ID, 125*Kbaud)
C.USER2 CAN (11*bit ID, 50*kbaud)
*default settings (user adjustable)
Works on all OBD2 Vehicles (1996 onwards in USA) and EOBD vehicles ( Petrol cars from 2001 and in Europe,we don\\\\\\\'t suggest to use it on diesel cars)
Alfa Rom.eo/ Ad/ Bentley/ BW/ Ca.dillac/ Che.vrolet/ Chrysl/ Citroen/ Daewoo/ Fiat/ Fo.rd/ G.M/ Hod/ Hyundai/ Isuzu/ Jaguar/ Je.ep/ Kia/ La.nd Ro.ver/ Lexus/ Mazda/ Mercury/ Mini/ Ni.ss.an/ Mitsubishi/ Opel/ Peugeot/ Posch/ Renault/ Rover/ Saab/ Seat/ Skoda/ Toyt/ Vauxhall/ Volvo/ VW
For your information:
For your vehicle to be OBD II compliant it must have a 16-pin DLC (Data Link Connector) under the dash and the Vehicle Emission Control Information Label must state that the vehicle is OBD II compliant.
Scantool_net113win (Full Version)
EasyOBDII V2.2 (Free Version)
OBD2Spy (Demo Version)
Scan Master-ELM (Demo Version)
wOBDCRAZY (Demo Version)
This hardware can match much other software still! But most of them are not free!
Works for Windows98/ME/2000/XP/Vista & 7!
This tool does not match abs and airbag system!
Bluetooth pair code: 1234 or 0000
Main Control Chip: PIC18F2480
Q: What\\\\\\\'s the version of this unit?
A: It\\\\\\\'s V2.1 version of this unit.
Q. What\\\\\\\'s the Password of the Bluetooth?
A: It\\\\\\\'s "1234" .
Q: If it can do all most car models and diesel car models?
A: No, it can just support most standard OBD II car models, and the J1850 protocols car models can\\\\\\\'t be support. Dieser car models can\\\\\\\'t be supported.
Q: Which android system phone can compatible? If it can compatible with Iphone?
A: Please kindly use Android V 4.0- 4.4 or V5.0, and android system can be supported.
Q: Why my computer can\\\\\\\'t connect with this Bluetooth?
A: This unit is with V2.0 version Bluetooth, check your computer if it\\\\\\\'s V2.0 version, or please use V2.0 bluetooth adapter.
Q:Why my phone can\\\\\\\'t connect with the Bluetooth?
A: Please kindly check if you choose the bluetooth connect way in software setting.
Q:My phone can connect with the unit, but it can\\\\\\\'t find my car?
A: 1. please check ifyou choose the "OBD II" adapter of " adapter choice" in setting software. 2. check the protocol of this car if it can be supported, and try with more new cars.
Q: If I still have question, what should I do now?
A: please kindly contact with the Seller, please don\\\\\\\'t ever open a dispute or just left a negative feedback. Thank you
A.1*EOBD / OBD2 Bluetooth Diagnostic Interface
