Report item
Item specifics
  • Electronic: No
  • Item Width: 10
  • Power: W
  • Material Type: plastic
  • Hardware Version: newest
  • Item Height: 10
  • External Testing Certification: CE
  • Model Name: BST-200
  • Software Version: newest
  • Voltage: V
  • Brand Name: ANCEL
  • Item Weight: 0.5
  • Item Length: 30
  • Item Type: Battery Testers
  • Special Features: Vehicle battery tester Auto battery analyzer
  • product: ANCEL BST-200
  • performance: strong and stable
  • quality: high quality
  • package: standard package
  • shipping : safe and fast
  • function: Battery Tester with Portable Design
  • model: BST-200 BST200 Battery Tester with Portable Design
Product Description

1

3



Why Choose Our Car Battery Tester?


1.Support Multi-languages: English, French, German, Italian, Dutch, Polish, Portuguese, Russian, Spanish, and Turkish.

initpintu__1

2.More accurate,exclusive patent,focus on test field

3. More economic, performance is as same as world famous one, lower price.

4. Easy to use, display result in 3 secs.

5. Good package, all goods are packed very well.

6. Fast delivery, we have abundant stock, may delivery goods in 1-2days.





Ancel BST200 Portable 12V Car battery load tester for car repair shop/ battery analyzer



Main function: Car battery test (12V battery)
Usage scope: All car lead-acid starter battery, including regular flooded, EFB, GEL, AGM Spiral, AGM Flat Plate
Suitable for: Automobile facory, garage, auto battery manufacturer, auto battery agent, educational institution, DIY enthusiasts, etc.
Test range: CCA100-800, 30-100Ah
Test result: SOH, SOC, CCA Value, IR, Starting & Charging system, etc.
Test standards: CCA, BCI, CA, MCA, JIS, DIN, IEC, EN, SAE, GB
Voltage measure range: 6-30VDC
Temperature measure range: -18 celsius ~ +70 celsius




How to Use(Battery Test)?


1.  Press UP/DOWN key to select the battery location ,in vehicle or out of vehicle , then press ENTER key to confirm.


in and out of vehicle



2. Press UP/DOWN key to select the battery charge state, then press ENTER key to confirm.In this way,it ensures a more accurate test result.(In vehicle ,select Before Bharge for Cold vehicle and After Bharge for Hot vehicle .)



before and after vehicle



3.Press UP/DOWN key to select battery type,then press ENTER key to confirm.



type



4.  5 types results

4. If the battery is tested in vehicle, you can continue to test starting and charging system of the car.



ANCEL BST-200 Battery Tester adopts currently the world\'s most advanced conductance testing technology to easily, quickly and accurately measure the actual cold cranking amps capability of the vehicle starting battery, healthy state of the battery itself, and common fault of the vehicle starting system and charging system, which can help maintenance personnel to find the problem quickly and accurately, thus to achieve quick vehicle repair.


ANCEL BST-200 BST200 Battery Tester Features:

1. Test all automotive cranking lead acid battery, including ordinary lead acid battery, AGM flat plate battery, AGM spiral battery, and Gel battery, etc.
2. Directly detect bad cell battery.
3. Polarity reverse connection protection, reverse connection will not damage the tester or affect the vehicle and battery.
4. Directly test the battery with loss of electricity, no need to full charge before testing.
5. Testing standards include currently the world\'s majority of battery standards, CCA, BCI, CA, MCA, JIS, DIN, IEC, EN, SAE, GB.


ANCEL BST-200 BST200 Battery Tester Functions:

Main functions of BST-200 battery tester include: battery test, cranking test, charging test and other additional functions.

1. Battery test is mainly targeted to analyze the battery healthy status to calculate the actual cold cranking capability of the battery and the aging extent, which provide reliable analysis evidence for the test and maintenance of the battery. It notifies the user to replace battery in advance when the battery getting aged.

2. Cranking test is mainly to test and analyze the starting motor. Through testing the actual required cranking current and cranking voltage of the starting motor, it can find out whether the starting motor works fine. There are several reasons why the starting motor is abnormal: lubricating system fault causing the starting loaded torque increasing or rotor friction of the starting motor causing the increasing friction of the starting motor itself.

3. Charging test is to check and analyze the charging system, including generator, rectifier, rectifier diode, etc., thus to find out whether the output voltage of the generator is normal, the rectifier diode works fine and the charging current is normal. Suppose one of the above mentioned parts is not in normal situation, it will lead to over charge or incomplete charge of the battery, thus the battery will be quickly damaged and also greatly shorten the using life of other loaded electrical appliance.

4. Additional functions include: Set language, voltmeter and screen brightness adjustment.



Working Environment Requirement

Working Environment Temp.: -20°C-60°C
It is applicable for automotive manufacturers, automotive maintenance and repair workshops, automotive battery factories, automotive battery distributors, and educational organizations, etc.


Package Including:

1pc x  ANCEL BST-200 BST200 Battery Tester



2

10_

984111412





Thanks for your concerns about our product.

Specification about shopping and after-sale service :



shipment



1.All orders will ship within 2 -3 business days.

2.It takes approximately 3-8 workdays by DHL, UPS, TNT, FEDEX ,7-25workdays to ship to your countries by EMS.

3.We will send the new tracking number to you within 24 hours after the goods shipped out.

4.We will not responsible for any wrong or undeliverable address.

5.if your area is remote area in DHL,UPS,TNT,FEDEX,EMS ,extra 35usd will be charged.



quality control



1.All items we are selling are brand new.

2. All items will be checked carefully before sent out, each item has a QC passed label.

3. Products will package by air bubbles envelope or carton.

4. If you have any quality problem, please contact us we will do our best to slove it asap. Please DO NOT open dispute or leave negative feedback before contacting us, it is not the best way to slove problem.  thank you!



return policy



If you are not satisfied with your purchase, please contact us within 3 days after you received, we can offer return for free repair, exchange or refund, buyers is responsible for the return cost .

Best regards!





Packaging Details
  • Unit Type: piece
  • Package Weight: 0.4kg (0.88lb.)
  • Package Size: 30cm x 10cm x 10cm (11.81in x 3.94in x 3.94in)
